XTND Audio (100) eARC.

The XTND Audio (100) eARC extends audio from a HDMI eARC capable display to an amplifier, AVR or Sonos Amp device up to a distance of 100m/328ft over Cat 6 cable. Offering both stereo and multi-channel digital audio support (Dolby Atmos & DTS) with seamless control through HDMI CEC, ensuring that you can use your display remote control to control the volume at your amplifier.

Manuals, software, drivers & media assets

Features

HDMI 2.0 and HDCP 2.2 device.
Transmit eARC or optical audio signals from your display up to 100m / 328 ft away over a single Cat 6 cable.
Supports CEC passthrough meaning that your display remote control can control the amplifier, AVR or Sonos Amp at the other end.
Works with all ARC and eARC formats (Dolby Atmos & DTS).

Specification

Form-factor Ultra-compact steel enclosure.
Audio Formats Dolby Atmos, DTS, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, PCM, Stereo and more.
Inputs HDMI (ARC/eARC), Optical.
Outputs HDMI (ARC/eARC), Optical.
Power Supply DC 12V/1A (US/EU standards, CE/FCC/UL certified).
Operating Temperature 32°F to 104°F (0°C to 40°C).
Dimensions (TX & RX) 90mm (W) x 72mm (D) x 20mm (H) / 3.54" x 2.83" x 0.78".
Weight 174g / 6.13oz.
